Setra Systems 26512R5WDACT1C Model 265, 0-2.5 inches WC, 24 VAC / 0-10 VDC, Terminal Strip, ±1%

Product Description

The Setra Systems 26512R5WDACT1C Model 265 differential pressure transducer provides superior positive and negative pressure sensing required for high-efficiency air-control systems. It features ±1.0% full scale accuracy (±0.4%, ±0.25% FS optional) with an available snap-on conduit enclosure molded from high-impact Lexan®. Designed for wall mounting, it measures pressure in Inches of Water Column.

• 1% accuracy improves variable air volume
• Optional accuracies 0.4% or 0.25% FS
• 24 VDC or 24 VAC excitation

Product Highlights

The Setra 265 pressure transducer is ideal for air-control systems, offering precise pressure sensing with multiple voltage options and robust construction.

Product Information

Standard Information

• Brand: SETRA SYSTEMS
• Manufacturer Part Number: 26512R5WDACT1C
• Country of Origin: US

Technical Specifications

• Measurement: Inches of Water Column
• Media Compatibility: Inert dry air
• Accuracy: 1%
• Output: 0 - 10 VDC
• Supply Voltage (Nominal): 24 VDC
• Mount: Wall
• Sensor Type: Capacitive
• Adjustments: (Z/S) Zero & Span trim POTs
• Overpressure: (Burst) ±10 psid (68.95 kPa)
• Operating Humidity: 10 to 95% Non-condensing
• Wetted Parts: Stainless steel
• Process Connection: 3/16'' OD plastic, for 1/4'' OD tubing
• Enclosure Rating: NEMA1 equivalent, plastic UL94-V-0
• Item Number: 26512R5WDACT1C
• Brand: Setra
