Setra Systems 26510R5WBABT1C Model 265, ± 0.5 inches WC, 0-5 VDC

Product Description

The SETRA SYSTEMS 26510R5WBABT1C pressure transducer provides accurate pressure readings within a range of 0-0.5" WC and outputs a corresponding 0-5 VDC signal for easy integration with monitoring and control systems. It provides superior positive and negative pressure sensing required for high-efficiency air-control systems. The Model 265 is a ±1.0% full scale accuracy unit.

• 1% accuracy improves variable air volume
• Optional accuracies 0.4% or 0.25% FS
• 24 VDC or 24 VAC excitation

Product Highlights

The transducer's robust construction features a durable stainless steel and aluminum housing, ensuring longevity and resistance to harsh industrial environments.

Product Information

Standard Information

• Brand: SETRA SYSTEMS
• Manufacturer Part Number: 26510R5WBABT1C

Technical Specifications

• Direction: Bi-Directional
• Measurement: Inches of Water Column
• Media Compatibility: Inert dry air
• Range: ±1 in WC
• Type: Fixed
• Accuracy: 1%
• Output: 0 - 5 VDC
• Supply Voltage (Nominal): 24 VDC
• Mount: Wall
• Supply Voltage: 9 to 30VDC @ 20 mA
• Signal Output: 0-5V @ 5KΩ, 4-20mA @ 750Ω (loop powered)
• Sensor Type: Capacitive
• Adjustments: (Z/S) Zero & Span trim POTs
• Overpressure: (Burst) ±10 psid (68.95 kPa)
• Operating Temperature: 0 to 150°C (-18 to 65°C)
• Operating Humidity: 10 to 95% Non-condensing
• Wetted Parts: Stainless steel
• Process Connection: 3/16'' OD plastic, for 1/4'' OD tubing
• Wiring Exposed terminals: 2-(4-20mA), 3-(Volts)
• Mounting: 2, #10 screws
• Enclosure Rating: NEMA1 equivalent, plastic UL94-V-0
• Approvals: CE
• Item Number: 26510R5WBABT1C
• Brand: Setra
