Setra Systems 231GMS22FD Wet-to-Wet Differential Pressure Transducer

Product Description

The Setra Systems 231GMS22FD Wet-to-Wet Differential Pressure Transducer is a versatile and robust device designed for accurate pressure measurement in a variety of applications. It features field-selectable pressure ranges and outputs, housed within a durable NEMA 4 rated enclosure with a hinged cover for easy operation.

• Multi-configurable with field-selectable pressure ranges and analog outputs.
• Optional LCD display for monitoring pressure levels.
• Robust NEMA 4 enclosure ensures durability in harsh environments.

Product Highlights

This transducer is ideal for use in energy management systems, process control, and flow measurement. It supports a broad range of applications from gas flow to liquid level measurement in pressurized containers.

Product Information

Standard Information

• Brand: Setra Systems
• MPN: 231GMS22FD

Technical Specifications

• Pressure Range: 10 to 100 psi
• Output: 4 to 20 mA
• Process Connection: 1/8-18 NPT Internal
• Max Pressure: 100 psi
• Supply Voltage: 15 to 30 VDC
• Electrical Connection: 1/2 in Conduit
• NEMA Rating: NEMA 4
• IP Rating: IP65
• Temperature Range: -4 to 185 Degrees F
• Compliance: CE, RoHS
