Setra's Model 231 is a multi-configurable, wet-to-wet differential pressure transducer offering the user an all-in-one device with field selectable pressure ranges and analog outputs. The device is offered with an optional 3 or 5 valve machined brass manifold for ease of installation and maintenance. The 231 has a robust NEMA 4 enclosure with an LCD display and a hinged, captive cover allowing for easy access to switches for adjusting the range and output.



Multi-Config. Wet Press. Transducer

/0-5

10

25

50 PSID

1/8NPT

LCD



Features:

4 Field Selectable Outputs

8 Field Selectable Pressure Ranges

Field Accessible Push-Button Zero & Remote Zero

Hinged Cover

Optional LCD Display

NEMA 4 Rated Housing, All Cast Aluminum

CE & Ro
HS Compliant

Specifications:

Manufacturer Part Number231GMS12FD
Item Number231GMS12FD
Manufacturer
Setra
Product Series231
Family Series
Setra HVAC Sensors, 231 Series
Pressure Range5~50 psi
Output4~20 m
A
Process Connection1/8-18 NPT Internal
Sensor Style
Differential
Max Pressure50 psi
Supply Voltage15~30 VDC
Electrical Connection1/2 in Conduit
NEMA Rating
NEMA 4
IP Rating
IP65
Temperature Range-4 to 185 Degrees F
Approvals
CE
Ro
HS Compliant
Yes
Net Weight1.53 lbs
Gross Weight1.72 lbs
