Setra MR2UA Differential Pressure Transducer (8 Ranges)

Product Description

Setra Systems MR2UA is a multi-range differential pressure transducer providing unidirectional or bidirectional sensing with eight field-selectable pressure ranges. It offers field-selectable outputs of 4–20 mA, 0–5 VDC, or 0–10 VDC, and operates from 13–30 VDC or 18–24 VAC. The MR2UA features IP67/NEMA 4 housing, barbed process connections, screw terminal wiring, field-selectable units (in. W.C. or Pa), and up to 10 psi overpressure protection.

• Field-selectable outputs (4–20 mA, 0–5 VDC, 0–10 VDC) and eight pressure ranges; accuracy ±1.000% FS (Ranges A–C), ±2.000% FS (Range D)
• Rugged IP67 / NEMA 4 enclosure with wall, panel, DIN rail, or standard mounting; barbed process connection and screw terminal wiring
• Operates on 13–30 VDC or 18–24 VAC; output resistance 10 ohms max; operating temperature 32–122 °F (0–50 °C); up to 10 psi overpressure

Product Highlights

Multi-range differential pressure transducer with field-selectable outputs and units, IP67/NEMA 4 enclosure, and up to 10 psi overpressure protection.

Product Information

Standard Information

• Brand: SETRA SYSTEMS
• Manufacturer Part Number: MR2UA
• Country of Origin: US

Technical Specifications

• Product Type: Differential pressure transducer
• Manufacturer: Setra Systems
• Manufacturer Part Number (MPN): MR2UA
• Sensing: Unidirectional or bidirectional
• Pressure Ranges: Eight field-selectable ranges
• Range: 0.5 to ±5 in. W.C.
• Output: 4–20 mA, 0–5 VDC, 0–10 VDC (field-selectable)
• Accuracy: ±1.000% FS (Ranges A–C); ±2.000% FS (Range D)
• Input Voltage: 13–30 VDC or 18–24 VAC
• Engineering Units: Field-selectable (in. W.C. or Pa)
• Enclosure Rating: IP67 / NEMA 4
• Mounting Type: Wall, panel, DIN rail, or standard (per suffix)
• Process Connection: Barbed
• Wiring: Screw terminal
• Overpressure: Up to 10 psi
• Output Resistance: 10 ohms max
• Operating Temperature: 32–122 °F (0–50 °C)
• Country of Origin: US
