Product Description
The SEPCO LL6CA is an aluminum combination conduit body made for two-inch trade size electrical systems. This conduit body provides easy access to electrical conductors for pulling, splicing, inspection, and maintenance. It is suitable for use with threaded rigid conduit, Intermediate Metal Conduit (IMC), and Electrical Metallic Tubing (EMT).
Designed with durability in mind, it is constructed from a copper-free aluminum alloy that resists corrosion and weather-related damage. The unit features tapered threaded hubs (NPT) and a flat back for easy installation against walls. It comes with a pre-assembled neoprene gasket and a stamped cover that is secured in place with slotted/Robertson combination screws.
- Provides access for pulling, splicing, inspection, and maintenance of conductors.
- Features tapered threaded hubs (NPT) and a flat back design for mounting close to walls.
- Manufactured from high-strength, corrosion and weather-resistant copper-free aluminum alloy.
Product Highlights
The SEPCO LL6CA simplifies electrical installations while ensuring durability and ease of access.
Product Information
Standard Information
-
Trade Size: 2
-
Standard Materials: Die cast/Copper-free Aluminum
Technical Specifications
-
DIM A: 10.06
-
DIM B: 4.44
-
DIM C: 3.63
-
Max Wire Size: 3 #4/0 AWG
-
Volume: 69.70 CU.IN.
-
Standard Finish: Aluminum Enameled
-
UL Listed: E198259
