SEPCO LL2 Malleable Iron Conduit Outlet Body 3/4-Inch LL2

Product Description

The SEPCO LL2 is a Type LL conduit outlet body made from malleable iron. This product connects with 3/4-inch threaded rigid or IMC conduit, allowing for access within an electrical raceway system. The body includes a screw-on cover and has a cubic capacity of 7.5. Its dimensions are five point three seven five inches in length, two point two five inches in width, and one point six eight eight inches in height. A zinc plating and aluminum enamel finish protect the unit. This outlet body enables easy access to conductors for maintenance and modifications.

• Constructed from durable malleable iron.
• Includes a screw-on cover for secure fitting.
• Compatible with 3/4-inch threaded rigid and IMC conduit.

Product Highlights

This conduit outlet body is ideal for electricians needing reliable connections in electrical systems.

Product Information

Standard Information

• Brand Name: SEPCO
• Product Name: SEPCO LL2 Malleable Iron Type LL Conduit Outlet Body

Technical Specifications

• Trade Size: 3/4 Inch
• Cubic Capacity: 7.5
• Cover Type: Screw-On
• Dimensions: 5.375 Inch Length x 2.25 Inch Width x 1.688 Inch Height
• Connection Type: Threaded
• For Use With: Threaded Rigid/IMC Conduit
• Material: Malleable Iron
• Finish: Zinc Plated, Aluminum Enameled
