Sensor Switch WSX D IV Wall Switch Sensor 120 to 277 VAC

Product Description

The Sensor Switch WSX D IV is a wall switch occupancy sensor designed for 120 to 277 VAC systems. This unit is suitable for various applications including closets, conference rooms, corridors, hotels, open offices, private offices, restrooms, and stairwells.

• Occupancy controlled dimming
• 180-degree sensing range
• Wired connection for easy installation

Product Highlights

This wall switch sensor provides reliable lighting control by detecting motion in its coverage area. It features a power rating of one quarter horsepower and is designed for mounting on walls.

Product Information

Standard Information

• Brand: Sensor Switch
• Manufacturer: Acuity Brands

Technical Specifications

• Catalog Number: WSX D IV
• MPN: WSX D IV
• Supply Voltage: 120 to 277 VAC
• Power Rating: 1/4 hp
• Sensing Type: Passive Infrared
• Sensing Range: Up to 20 ft
• Viewing Angle: 180 degrees
• Temperature Rating: 14 to 122 degrees Fahrenheit
• Material: Plastic
• Dimensions: 2.74 in H x 1.68 in W x 1.63 in D
• Mounting Type: Wall
