Selecta SS207-7A-BG SEL Toggle Switch DPST 20AMP@125VAC 10AMP@250VAC

Product Description

Selecta Toggle Switch SS207-7A-BG is designed for heavy-duty applications. It operates at 125 VAC and 250 VAC, with an amperage rating of 20 Amps at 125 VAC and 10 Amps at 250 VAC. This example of a double pole single throw (DPST) switch features a bat handle for easy operation. The switch includes threaded mounting for secure installation and screw terminals for reliable connections.

• Heavy duty toggle switch
• Rated for 20/10 Amps
• Dimensions: 1.3 inches long, 0.75 inches wide, 2.36 inches high

Product Highlights

This switch is ideal for controlling a variety of electrical devices in residential and commercial settings. It provides consistent performance in demanding situations.

Product Information

Standard Information

• Manufacturer: Selecta Products
• UPC: 66119110370

Technical Specifications

• Actuator: Bat Handle
• Amperage Rating: 20/10 A
• Contact Configuration: DPST
• Dimensions: 1.3 in L x 0.75 in W x 2.36 in H
• Manufacturer Part Number: SS207-7A-BG
• Mounting: Threaded
• Number of Poles: 2
• Standards/Approvals: UR Listed
• Terminal Type: Screw
• Type: Heavy Duty
• Voltage Rating: 125/250 VAC
