Seco SECOT-31506 Turning Insert WNMG432-MF4 TM4000 080408

Product Description

Seco 31506 Turning Insert features ANSI code WNMG432-MF4 TM4000. This turning insert is suitable for machining processes, especially on stainless steel materials. It provides effective cutting results with its trigon shape and neutral cutting direction. This insert serves various applications, particularly in medium and finishing tasks.

• Insert style: WNMG with a trigon shape
• Material: carbide, suitable for stainless steel
• Thickness: 4.76 mm, optimal for precision cutting

Product Highlights

This turning insert operates effectively on stainless steel and offers a maximum depth of cut of five mm.

Product Information

Standard Information

• Brand: Seco
• MPN: SECOT-31506

Technical Specifications

• ANSI Code: WNMG432-MF4 TM4000
• Chipbreaker: MF4
• Corner Radius: 0.8 mm
• Finish: CVD-TiCN+Al2O3 Coated
• Hole Diameter: 5.15 mm
• ISO Code: WNMG080408-MF4 TM4000
• Included Angle: 80 degrees
• Inscribed Circle: 12.7 mm
• Maximum Depth of Cut: 5 mm
• Relief Angle: 0 degrees
• Thickness: 4.76 mm
• Material Grade: M
• Insert Size: 080408
• Shape: Trigon
• Seat Size: 08
• Rake: Negative
• Cutting Direction: Neutral
• For Use On: Stainless Steel
