Seco-Larm SK-2612-SFSQ Fingerprint Reader and Keypad

Product Description

The Seco-Larm SK-2612-SFSQ Fingerprint Reader and Outdoor Keypad is an advanced security solution that offers both efficiency and convenience. This versatile device can function as a standalone controller or a Wiegand reader. It operates at 12VDC and has a Form C relay output of 2A@12VDC.

• 12VDC Operation
• Low current draw – 210mA max.
• Form C relay output – 2A@12VDC

Product Highlights

Offers keyless entry with fingerprint and PIN options, supporting up to 3,000 users. Features adjustable output, tamper alarm, and IP66 weatherproof rating.

Product Information

Standard Information

• Brand: Seco-Larm
• Manufacturer Part Number: SK-2612-SFSQ
• Country of Origin: China

Technical Specifications

• Operating Voltage: 12VDC
• Current Draw: Standby: 60mA@12VDC
• Current Draw Active: 210mA@12VDC (max.)
• Outputs: Form C: 2A@12VDC
• Outputs Tamper Alarm: 2.5A@12VDC
• Wiegand: 26~37 bits
• Inputs: Wiegand: 26~37 bits, PIN input – 4, 8, or 10 bits
• Egress Input: N.O. Ground
• Door Sensor Input: N.C. Ground
• Enclosure Material: Zinc alloy
• Operating Temperature: -40°~140° F (-40°~60° C)
• Operating Humidity: 20~90% non-condensing
• Adjustable output: 1~99 seconds or toggle
• Outdoor rated: IP66 weatherproof
• Fingerprint identification time: ≤1 second
• Fingerprint false acceptance rate: ≤0.01%
• Fingerprint false rejection rate: ≤0.1%
• Manufacturer Part #: SK-2612-SFSQ
• UPC: 676544020431
• User code length: 4~6 digits
• Weatherproof: IP66
• Illuminated fingerprint reader window: Yes
• Wiegand output: 26~44 bit
• Users: Up to 3,000 (up to 1,000 fingerprint users, up to 2,000 PIN users)
• Credentials: FCC
