Seco 74072248 Anvil Indexable 0.375 Inch Insert

Product Description

The SECO 74072248 is a replacement anvil designed for indexable toolholders used in metal cutting and turning applications. The anvil seats beneath the insert to provide a stable, rigid support surface that protects the toolholder pocket and distributes cutting forces evenly. It is sized for a 0.375 inch insert inscribed circle and is compatible with Style L and Style T insert geometries in size 3. This component is installed by machinists and toolroom technicians maintaining indexable cutting tool assemblies on CNC lathes and turning centers.

This anvil is suited for use in production machining environments where indexable inserts are regularly rotated or replaced. It fits toolholder insert size code 3 in both Style L and Style T configurations and uses the S-34 anvil screw for retention. The anvil is sold individually and is available in minimum order multiples of 10, making it appropriate for shop stock replenishment and tool crib management.

Key Features

• Designed for 0.375 inch insert inscribed circle diameter
• Compatible with Style L and Style T insert geometries, size code 3
• Uses S-34 anvil screw for secure retention in the toolholder pocket
• Industry Standard Number 19280 for cross-reference purposes
• Sold per piece with minimum order quantity of 10 units

Compatibility

Compatible with indexable toolholders accepting a size 3 insert in Style L and Style T configurations with a 0.375 inch inscribed circle. Requires S-34 anvil screw for proper installation.

Installation Notes

Anvil replacement is performed by machinists or toolroom technicians during routine toolholder maintenance. Always remove the tool assembly from the machine spindle or turret and ensure all moving axes are locked out before disassembling the insert pocket. The anvil screw (S-34) should be replaced if worn or damaged to ensure proper clamping torque distribution. Inspect the toolholder pocket seating surface for debris or damage before installing the new anvil.
