Seco 17013488 Roughing End Mill 3/16 in 4 Flute Cobalt

Product Description

The SECO 17013488 is a single-end roughing end mill designed for aggressive material removal in milling applications. Built from M42 cobalt high-speed steel and finished with a TiCN coating, this tool handles demanding cuts where standard HSS tooling falls short. It features a 3/16-inch mill diameter, a 1/2-inch length of cut, and a 3/8-inch shank diameter. The right-hand cutting direction and right-hand spiral flute geometry suit standard milling spindles. Four flutes with a chipbreaker-style roughing profile reduce cutting forces and help clear chips efficiently during heavy stock removal passes.

This end mill is suited for machining ferrous metals, stainless steels, and other tough alloys in manual or CNC milling operations. The regular-length body and 2-3/8-inch overall length make it a practical choice for shallow-to-moderate depth slotting, peripheral milling, and profile work on small-envelope parts. It is used in job shops, tool rooms, and production environments where cobalt tooling is preferred over carbide for interrupted cuts or workpiece setups with some deflection risk.

Key Features

• M42 cobalt construction for superior heat and wear resistance compared to standard M2 HSS
• TiCN coating reduces friction and extends tool life in ferrous and stainless applications
• 3/16-inch mill diameter with 1/2-inch length of cut for precise small-feature milling
• 4-flute geometry balances chip clearance with surface finish on roughing passes
• 30-degree maximum helix angle promotes stable cutting and reduced chatter
• Right-hand cut and right-hand flute direction compatible with standard milling spindles
• 3/8-inch shank fits common collet and end mill holder tooling systems

Compatibility

Designed as a direct-fit roughing end mill for milling machines, machining centers, and CNC routers equipped with a 3/8-inch collet, end mill holder, or shrink-fit tooling. Part of the SECO REM710 series.

Installation Notes

Installation should be performed by a qualified machinist or tooling technician. Ensure the spindle is fully stopped and the machine is powered down before changing tooling. Secure the shank to the full recommended engagement depth in the holder and verify runout with a dial indicator before cutting. Do not exceed the tool manufacturer's recommended speeds and feeds for the workpiece material and cut depth.
