Seco 17002331 Corner Radius End Mill 1/2 in 7 Flute Altin Carbide

Product Description

The SECO 17002331 is a solid carbide corner radius end mill designed for high-performance milling in demanding metalworking applications. It features a 1/2 inch diameter, a 7-flute configuration with close pitch spacing, and an AlTiN PVD coating that supports elevated cutting temperatures and extended tool life. The 0.0150 inch corner radius reduces stress concentration at the cutting edge, making this tool suitable for both roughing and finishing passes in a single setup. It is installed in standard straight-cylindrical toolholders and is intended for use by machinists and CNC operators working with ferrous and high-temperature alloys.

This end mill is built for milling steel, stainless steel, cast iron, superalloys, and titanium. The short flute length of 3/4 inch (0.7500 inch) and 3 inch overall length make it well suited for close-tolerance profiling, slotting, and contouring where rigidity and finish quality are critical. The right-hand flute direction and right-hand cutting geometry are standard for conventional vertical and horizontal machining centers. It is part of the S738R series, a line optimized for close-pitch roughing and finishing on difficult-to-machine materials.

Key Features

• AlTiN PVD coating for heat resistance and extended tool life in ferrous and superalloy materials
• 7-flute close-pitch design supports higher feed rates and improved surface finish
• 0.0150 inch corner radius reduces edge chipping and improves corner strength
• Solid micrograin carbide substrate for rigidity and wear resistance
• Single-end, non-centercutting geometry suited for side milling, profiling, and finishing passes
• 38-degree helix angle promotes efficient chip evacuation in short-flute applications

Compatibility

Designed for use with standard straight-cylindrical toolholders accepting a 1/2 inch shank diameter. Compatible primary workpiece materials include steel, stainless steel, cast iron, superalloys, and titanium (material codes P, M, K, S).

Installation Notes

Installation is performed by qualified machinists or CNC setup technicians. The machine spindle must be fully stopped and the toolholder secured before inserting or removing the end mill. Verify runout against the TIR maximum of 0.0005 inch after seating to confirm proper holder engagement. Do not use this tool for plunge cutting, as it is a non-centercutting design.
