Seco 03277879 Indexable Slotting Cutter 2in Combimaster

Product Description

The SECO 03277879 is an indexable slotting cutter designed for slotting, side milling, and disc milling operations on CNC machining centers and manual milling machines. Part of the R335.19 series, it features a 2 inch cutter diameter with a 0.25 inch cutting width and delivers a maximum depth of cut of 0.6020 inches. The cutter uses a Combimaster modular connection with an M12 modular connection size, allowing quick tool changes without removing the arbor. It accepts 2 SNHQ-style inserts held by screw clamping and is rated for a maximum spindle speed of 12,300 RPM. Installation is performed by qualified machinists and tooling specialists.

This cutter is suited for general-purpose slotting and side milling in a range of workpiece materials. The staggered tooth configuration with negative axial and negative radial rake geometry supports stable cutting action and predictable chip formation. The 4-tooth, coolant-through design makes it appropriate for both dry and wet cutting environments where through-spindle coolant is available. It is well matched to production and job shop environments running standard vertical or horizontal machining centers equipped with a Combimaster-compatible toolholder.

Key Features

• R335.19 series Combimaster connection with M12 modular connection size for fast, repeatable tool changes
• 2 inch cutter diameter with 0.25 inch cutting width and 0.6020 inch maximum depth of cut
• Staggered tooth design with negative axial and negative radial rake for stable slotting performance
• Accepts 2 SNHQ1204 inserts (compatible styles: SNHQ1204..L+R and 335.19-1204) secured by screw clamping
• Coolant-through capability supports extended tool life in high-volume cutting applications
• Right-hand cutting direction; rated to 12,300 RPM maximum

Compatibility

Compatible inserts include SNHQ1204..L+R and 335.19-1204. The cutter body is designed for use with Combimaster-compatible toolholders in the R335.19 toolholder style. Verify modular connection compatibility with the spindle interface before installation.

Installation Notes

This cutter is installed and serviced by qualified machinists or tooling technicians. Disengage spindle power and follow machine lockout/tagout procedures before mounting or removing the cutter body or inserts. Torque the Combimaster connection and insert screws according to the machine tool and insert manufacturer documentation supplied with the tooling. Inspect insert seating and clamping security before initiating a cut.
