Seco 02925830 Modular Reamer Body 12mm Straight Shank

Product Description

The SECO 02925830 is a modular reamer body designed for precision hole-finishing operations in metalworking and machining applications. It accepts a straight shank with a 12mm diameter and a shank length of 45mm, providing a stable interface for axial clamping systems. The overall assembled length is 167mm, and the body is constructed from steel for rigidity and wear resistance. This component serves as the holder body in a modular reamer system, accepting interchangeable cutting heads to allow flexible bore sizing without replacing the entire tool assembly. It is installed and used by machinists and CNC operators in production and job-shop environments.

This reamer body is compatible with the PMX5, PMX6, and PMX8 modular cutting head systems. It is suited for use in machine tool spindles where axial clamping is the required retention method. The neutral cutting direction makes it appropriate for standard right-hand machine setups. Typical applications include finish reaming of through-holes and blind holes in steel, cast iron, and similar machinable materials in both low-volume job-shop and higher-volume production settings.

Key Features

• Straight shank design with 12mm diameter for consistent spindle and collet chuck fit
• Axial clamping method ensures secure head retention during reaming operations
• Neutral cutting direction compatible with standard right-hand machine spindle rotation
• Steel construction provides rigidity and dimensional stability under cutting loads
• Modular system compatibility with PMX5, PMX6, and PMX8 cutting heads reduces tooling inventory
• Overall length of 167mm suits a range of machine spindle reach requirements

Compatibility

Designed for use with SECO PMX5, PMX6, and PMX8 modular reamer cutting heads using axial clamping retention.

Installation Notes

Installation should be performed by a qualified machinist or tooling technician with the machine spindle powered down and locked out per applicable machine safety procedures. The shank should be seated fully in the collet chuck or toolholder before tightening to the machine manufacturer's specified clamping torque. Inspect the shank and clamping surfaces for debris or damage before assembly. Cutting head attachment must follow the SECO modular system assembly instructions to ensure proper axial seating and runout performance.
