Seco 02807359 Indexable Drill Insert SCGX09P2 DP3000

Product Description

The SECO 02807359 is a solid carbide indexable drill insert designed for use with Perfomax series indexable drills. Identified by insert style SCGX and chipbreaker designation P2, this insert carries the DP3000 manufacturer grade with a Duratomic coating process for extended tool life across a range of workpiece materials. The 90-degree square shape provides a reliable cutting geometry, while the 7-degree relief angle reduces friction at the cutting edge. At 0.375 inches inscribed circle diameter and 0.156 inches thickness, this insert fits standard 09T308 insert size toolholders. Licensed machinists and CNC operators install these inserts as part of precision drilling operations in production and job-shop environments.

This insert is rated for universal primary workpiece material compatibility, covering material codes H, K, M, P, and S. That range includes hardened steels, cast iron, stainless steels, carbon and alloy steels, and heat-resistant superalloys. The Perfomax series platform is a common choice in high-productivity drilling applications where consistent chip control and repeatable insert indexing are required. The P2 chipbreaker geometry supports through-coolant drilling setups common in CNC machining centers and dedicated drill presses running production volumes.

Key Features

• Insert style SCGX with 90-degree included angle and 7-degree relief angle for positive cutting action
• DP3000 grade with Duratomic coating process for wear resistance across diverse workpiece materials
• P2 chipbreaker for controlled chip evacuation in drilling applications
• 0.375 inches inscribed circle and 09T308 insert size for direct Perfomax toolholder fit
• Universal material compatibility spanning H, K, M, P, and S material code classifications
• Solid carbide substrate for dimensional stability and edge retention at elevated cutting speeds

Compatibility

Designed for use in Perfomax series indexable drill bodies that accept SCGX 09T308 insert size seats. Compatible with workpiece material codes H, K, M, P, and S as designated by the manufacturer. Verify toolholder seat geometry and torx screw size before installation.

Installation Notes

Indexable insert replacement is performed by machining professionals following standard toolroom procedures. Ensure the spindle is stopped and the machine is in a locked-out, de-energized state before accessing the toolholder. Use the correct insert screw and manufacturer-specified drive key to seat the insert; do not over-tighten or substitute fasteners. Inspect the pocket seat for chips or debris before indexing or replacing the insert to maintain proper seating and runout tolerances.
