Seco 02685793 Indexable Face Mill 2.48in 5 Insert

Product Description

The SECO 02685793 is an indexable chamfer angle face mill designed for facing operations on machining centers and milling machines. Built to Series R220.48 standards, it accepts 5 ON.U09 inserts and delivers a maximum depth of cut of 0.236 inches across a minimum cutting diameter of 2.48 inches and a maximum cutting diameter of 3.071 inches. The cutter runs right-hand direction with a negative rake angle of -8 degrees, making it well-suited for aggressive material removal on ferrous and non-ferrous workpieces. Machinists and tooling technicians working in production shops or job shops are the primary installers and operators of this tool body.

This face mill fits horizontal and vertical milling setups where a 3/4-inch arbor hole is available. It is used in facing applications requiring a 40-degree chamfer angle geometry. With a maximum rated speed of 4,900 RPM, it is appropriate for both conventional and CNC milling operations in production environments. The overall height of 1.575 inches and hub diameter of 1.26 inches suit standard arbor and adapter configurations common in mid-size machining operations.

Key Features

• Series R220.48 cutter body with 40-degree indexable chamfer angle geometry
• Accepts 5 ON.U09 inserts secured by screw-clamp holding method
• Right-hand cut with negative rake angle of -8 degrees for controlled chip formation
• Maximum RPM rating of 4,900 for compatibility with common spindle speeds
• Normal pitch configuration with 10 flutes for balanced cutting performance
• 3/4-inch arbor hole with 8.20 mm keyway width for positive drive engagement

Compatibility

Designed as an OEM-style replacement and production tooling body compatible with standard 3/4-inch arbor adapters and accepting ON.U09 series indexable inserts as specified for the R220.48 cutter series.

Installation Notes

Installation should be performed by a qualified machinist or tooling technician. Always power down and lock out the spindle before mounting or removing the cutter body from the arbor. Verify insert seating and screw torque per insert manufacturer guidelines before running the tool. Confirm maximum RPM of the spindle does not exceed the 4,900 RPM rating of this cutter body.
