Seco 02459014 Round Milling Insert RDKW0803M0T-MD05 F40M

Product Description

The SECO 02459014 is a round solid carbide milling insert in the RDKW series, designed for use in high-performance face and copy milling operations. It carries the F40M manufacturer grade and features a PVD-applied TiAlN plus TiN dual coating for wear resistance and thermal stability. The insert is 0.125 inches thick with an inscribed circle of 0.315 inches and a corner radius of 0.1575 inches. Four cutting edges are available on this single-sided neutral-rake insert. The T-Land cutting edge style helps manage entry forces and reduces chipping on interrupted cuts. Licensed machinists and CNC operators are the primary users of this insert in production and job-shop environments.

This insert is suited for milling steel, stainless steel, cast iron, non-ferrous metals, superalloys, and titanium. It fits applications where controlled chip formation and reliable edge life are priorities, including roughing and semi-finishing passes. The MD05 chip breaker geometry is optimized for moderate feed rates on these material groups. Compatible cutter bodies in the R217.29-04 and R220.29-04 series accept this insert directly. It is held in place by a screw-lock method, which is standard on RDKW-style toolholders.

Key Features

• Round insert shape with 360-degree included angle provides consistent edge engagement and easy indexing
• Solid carbide fine-grain substrate with PVD TiAlN plus TiN coating for extended tool life in steel and cast iron
• Four usable cutting edges on a single-sided insert maximize value per insert
• MD05 chip breaker geometry supports controlled chip evacuation across multiple workpiece materials
• Neutral rake and T-Land edge prep reduce insert shock during entry and on interrupted cuts
• Maximum depth of cut of 0.1575 inches with a 15-degree relief angle for clean finish surfaces

Compatibility

Designed for use with SECO cutter bodies in the R217.29-04 and R220.29-04 series. Conforms to ANSI and ISO code RDKW0803M0T-MD05 within the RDKW-08 insert series.

Installation Notes

This insert is installed by a machinist or CNC tooling technician. Power down and lock out the machine spindle before indexing or replacing inserts. Use the correct torx or hex key to the toolholder manufacturer's specified seating procedure when tightening the clamp screw — do not overtighten. Inspect the insert pocket seat for chips or debris before seating a new insert to ensure full contact and accurate positioning.
