Schneider Electric ZBVM1 Square D 22 mm 230 to 240 VAC White Push Button Light Module

Product Description

The Schneider Electric ZBVM1 is a light module that operates with a universal LED. It runs on a voltage range of two hundred thirty to two hundred forty volts AC and connects using screw clamp terminals. This light module's plastic body facilitates easy installation and replacement on compatible illuminated push-button or selector switch units.

• Designed for fast configuration of signaling units.
• Operates effectively over a wide temperature range of minus forty degrees Celsius to seventy degrees Celsius.
• IP20 protection index safeguards against contact with live circuits.

Product Highlights

The ZBVM1 allows for quick replacement and setup, ensuring visual distinction of signaling units via the LED illumination. It enhances operational safety and minimizes downtime due to its high-endurance LED lighting.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Catalog Number: ZBVM1

Technical Specifications

• Voltage: 230/240 VAC
• Current: 19 mA
• Weight: 0.04 lb
• Operating Temperature: -40 to 70 degrees C
• Light Source: Protected LED
• Connection Type: Screw Clamp
• Country of Origin: France
• Warranty Length: 18 months
