Schneider Electric ZB6EG5B 16mm Push Button Yellow 48V to 120V LED Light Module

Product Description

The Schneider Electric ZB6EG5B is a 16mm push button featuring a yellow LED light module designed for applications with limited surface area. This unit operates within a voltage range of forty-eight to one hundred twenty volts, making it versatile for various electrical setups.

• Dimensions: 0.61 inches tall, 0.24 inches wide, and 2.28 inches deep
• Includes faston terminals measuring 2.8 x 0.5 mm
• Certification: UL and CSA approved for safety

Product Highlights

This light module is ideal for control boards, alarms, and small machines. Its compact size allows for easy installation in tight spaces, ensuring effective signaling and control.

Product Information

Standard Information

• Catalog Number: ZB6EG5B
• Manufacturer: Schneider Electric

Technical Specifications

• Voltage Range: 48V to 120V
• Height: 0.61 inches
• Width: 0.24 inches
• Depth: 2.28 inches
• Weight: 0.01 lbs
• Country of Origin: Mexico
• Warranty: 18 months
• Standards Compliance: Meets JIS C 4520, CSA C22.2 No 14, EN/IEC 60947-5-5, UL 508 standards
