Schneider Electric ZB5AW0G15 Led Indicating Light

Product Description

The SCHNEIDER ELECTRIC ZB5AW0G15 is an LED indicating light designed for panel-mount applications in industrial and commercial control systems. Rated for 110-120 volts, it features a white lens and uses an LED lamp type for long-lasting, low-heat illumination. The unit connects via screw clamp terminals, providing a secure, tool-assisted termination point that reduces the risk of loose connections under load. Built with vibration resistance, it maintains reliable operation in environments where mechanical stress is a regular factor. Electricians and panel builders install this component as a status or pilot indicator in control enclosures, machine panels, and operator interface stations.

The ZB5AW0G15 is suited for use in industrial control panels, automation systems, and marine or heavy-equipment environments where vibration resistance and multi-standard certification are required. Its white lens provides neutral-color indication, commonly used for power-on or general status signaling. The compact form factor fits standard 22 mm panel cutouts typical in control panel construction. It meets a broad range of international and North American standards, making it appropriate for projects that require UL Listed components or compliance with IEC and CSA requirements.

Key Features

• LED lamp type for extended service life and low heat output
• Rated 110-120 volts for direct connection to standard North American control circuits
• White lens for neutral-color status indication
• Screw clamp connector for secure, vibration-resistant wiring termination
• Vibration-resistant construction suited for industrial and marine installations
• Certified to multiple standards including UL Listed, CSA, DNV, GL, RINA, and IEC 60947-5-1

Compatibility

Designed as an OEM-style replacement or new-install LED pilot light for 22 mm panel cutout control enclosures and operator interface stations requiring 110-120 volt indicating lights.

Installation Notes

Installation is typically performed by a licensed electrician following NEC guidelines for industrial control panel wiring. De-energize the panel and verify absence of voltage before removing or installing any indicating light. Screw clamp terminals should be tightened with an appropriate flat-blade screwdriver to the connector manufacturer's specified range. Confirm the panel voltage matches the 110-120 volt rating of this device before commissioning.
