Schneider Electric ZB5AA7341 Push-button Switch 22mm

Product Description

The SCHNEIDER ELECTRIC ZB5AA7341 is a 22 mm momentary push-button switch designed for industrial control panel applications. The assembly features dual-color flush-mount pushbuttons in green and red, housed in a chromium-plated metal bezel, and operates on a momentary (MO) On-Off sequence. It is non-illuminated. The unit is rated for shock and vibration resistance, making it suitable for demanding environments where panel-mounted switching must hold up to mechanical stress. Licensed electricians and industrial maintenance technicians are the primary installers for this type of control device.

This switch is intended for use in industrial and commercial control panels where a compact, flush-mount momentary operator is required. The 22 mm mounting hole diameter is a standard size widely used in motor control centers, machine control stations, and process control enclosures. The NEMA 4X and NEMA 13 ratings indicate suitability for washdown, dust-tight, and corrosion-resistant installations. The rectangular pushbutton profile accommodates panel layouts where standard round operators are not specified.

Key Features

• 22 mm standard mounting hole diameter for broad panel compatibility
• Momentary (MO) operation with On-Off switch sequence
• Dual-color operators: green and red flush-mount rectangular pushbuttons
• Non-illuminated design simplifies wiring and reduces component count
• Chromium-plated metal bezel for durability in industrial environments
• NEMA 4X and NEMA 13 rated; shock-resistant and vibration-resistant

Compatibility

Designed as an OEM-style replacement or new-installation momentary push-button switch for 22 mm industrial control panel cutouts meeting NEMA 4X and NEMA 13 enclosure requirements.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC Article 430 and applicable local codes. De-energize and lock out the control panel before installing or replacing any control device. Verify the panel cutout is 22 mm and that the enclosure rating matches the operating environment before mounting. Do not overtighten the mounting nut, as this can crack the bezel or distort the panel surface.
