Schneider Electric ZB4BW0G11 Square D 22 mm 110 to 120 VAC 1NO White Single Contact Block Light Module with LED

Product Description

The Schneider Electric ZB4BW0G11 is a light module with a single normally open (1NO) contact, designed for use in control applications requiring visual indication. This module is a part of the Harmony XB4 series and operates on a voltage range of one hundred ten to one hundred twenty volts alternating current. It features a universal LED for illumination, enhancing visibility in various environments.

• Universal LED illumination
• Impact and water resistant with IP66 rating
• Compatible with Harmony XB4 pilot devices

Product Highlights

This module is suitable for both new installations and replacements, ensuring efficient operation in diverse conditions, including extreme temperatures from negative forty degrees to fifty-five degrees Celsius. The installation is straightforward, utilizing screw clamp connections for secure attachment.

Product Information

Standard Information

• Catalog Number: ZB4BW0G11
• Manufacturer: Schneider Electric

Technical Specifications

• Size: 30 mm width, 47 mm height
• Current Rating: 14 mA
• Voltage Rating: 600 volts
• Amperage Rating: 10 amps
• Contact Configuration: 1 NO
• Warranty Length: 18 months
• Country of Origin: France
• Storage Temperature: -40 to 70 degrees Celsius
