Schneider Electric ZB4BV6120 Pilot Light Collar 120V

Product Description

The SCHNEIDER ELECTRIC ZB4BV6120 is a pilot and indicator light mounting collar combined with an integrated light module, designed for use in industrial and commercial control panel applications. Rated at 120 volts supply voltage, this assembly provides both the mechanical mounting interface and the illumination component in a single unit. Electricians and panel builders install this part when building or servicing operator interface stations, push-button assemblies, or control enclosures that require a flush or standard-mount indicator light. The compact form factor keeps panel layouts clean while delivering reliable visual status indication.

This mounting collar with light module is suited for control panel construction and maintenance in commercial and industrial environments. It fits into standard 22 mm operator interface cutouts commonly found in machine control stations, HVAC control panels, and process equipment enclosures. The part is typically sourced as a direct replacement or new-build component when upgrading or repairing pilot light assemblies. Electricians working on low-voltage control circuits will find this unit straightforward to integrate into existing ZB4 series operator interface hardware.

Key Features

• Integrated mounting collar and light module in one assembly for simplified installation
• 120 volt supply voltage rating suitable for standard North American control circuits
• Compact dimensions of 2.4 inches length, 1.7 inches width, and 1.3 inches height
• Lightweight construction at 0.13 pounds, minimizing added panel weight
• Sold as a single unit, with no minimum quantity requirement beyond one piece

Compatibility

Designed as an OEM-style replacement or new-build component for standard 22 mm pilot and indicator light operator interface assemblies requiring a 120 volt light module.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize the control panel and verify zero voltage with a meter before handling any wiring or mounting components. Secure the collar into the panel cutout per the manufacturer torque and locking ring guidance for the ZB4 series. Confirm supply voltage matches the 120 volt rating of this module before restoring power.
