Schneider Electric VT2343H13A020 Valve Assembly 2 Way Zone Flare Replacement MPN

Product Description

Schneider Electric VT2343H13A020 is a zone valve assembly designed for effective fluid control in heating and cooling systems. This valve has a body size of three-fourths of an inch and operates as a two-way valve. It's suitable for use with glycol and water mixtures, providing reliable performance.

• Body Size: 3/4 in
• Actuator Type: Electric
• Control Signal: 2-Position (On/Off)

Product Highlights

This valve assembly operates under a close-off pressure of thirty PSI. It features a rotary actuator type and is powered by twenty-four volts AC. The unit includes a spring return for loss of power, ensuring safety and efficiency.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Product Line: Erie PopTop

Technical Specifications

• Flow Coefficient: 3.5 cv
• Protection Rating: IP31
• Ambient Air Temperature for Operation: 0-40 °C
• Power Consumption: 7.5 VA AC
• Mechanical Movement: Rotary
• Control Media: Glycol 25 to 50% and Water
• Seat Leakage: Class IV (0.01 %)
• Body Material: Forged Brass
