Schneider Electric VS-7263-537-4-11 Globe Valve Assembly, 2 Way, 2 in.

Product Description

The Schneider Electric VS-7263-537-4-11 is a globe valve assembly designed for HVAC applications. This two-way valve features a two-inch NPT connection and is equipped with a robust stainless steel trim, ensuring durability in various service environments.

• Direct coupled actuator with a spring return mechanism.
• Modulating control with 24 VAC/DC power requirements.
• Supports a feedback range of two to ten VDC.

Product Highlights

This valve assembly is ideal for controlling water, steam, and glycol mixtures in HVAC systems. It operates smoothly within a temperature range of negative twenty-two degrees Fahrenheit to one hundred forty degrees Fahrenheit and has a flow characteristic that is modified linear.

Product Information

Standard Information

• Brand: Schneider Electric
• Part Number: VS-7263-537-4-11

Technical Specifications

• Housing: NEMA 2, IP54
• Service: Glycol 25 to 60%, Steam, Water
• Stem Action: Up Open
• Auxiliary Switch: 1 x SPDT
• Power Consumption: 24 VAC/DC, 5.6 VA
• Flow Characteristic: Modified Linear
• Operating Conditions: -22 F to 140 F (-30 C to 60 C)
• Electrical Connections: 3 ft. Plenum Rated Cable with 1/2 in. Conduit Connector
