Schneider Electric VS-7263-537-4-10 SmartX Globe Valve Assembly 1-1/2 in 2-Way MS40-7043-501

Product Description

The Schneider Electric VS-7263-537-4-10 is a SmartX globe valve assembly designed for efficient fluid control in various applications. This valve features a body size of one and a half inches and operates as a two-way configuration. It is suitable for systems requiring enhanced precision and control.

• Body size: 1-1/2 inches
• Type: Electric actuator
• Flow coefficient: 28 cv

Product Highlights

This valve assembly is ideal for use in HVAC systems, providing reliable control of water and other fluids.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufactured in: US

Technical Specifications

• Configuration: 2-Way
• Material Trim: Stainless Steel
• Close-Off Pressure: 50 PSI
• Control Signal Range: 2 to 10 VDC, 4 to 20 mAdc
• Power Input Voltage: 24 VAC/VDC, 22 to 30 VDC
• Protection Rating: NEMA 2
• Ambient Air Temperature for Operation: -30 to 60 °C
• Torque: 35 in-lb
