Schneider Electric VS-7223-537-4-06 SmartX Globe Valve Assembly 3/4 in 2-way

Product Description

Schneider Electric VS-7223-537-4-06 is a SmartX globe valve assembly, designed for effective control in HVAC systems. This valve features a three-quarter inch body size and operates as a two-way valve with a straightway body pattern. The valve is suitable for applications requiring precision flow control.

• Body Size: 3/4 inch
• Operating Pressure: 250 PSI
• Electrical Compatibility: 24 VAC/VDC

Product Highlights

This valve assembly uses a brass body and a spring return mechanism. It ensures reliable operation with a torque rating of thirty-five inch-pounds. The design supports a range of control signals which makes it versatile for different applications.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Schneider Electric

Technical Specifications

• Configuration: 2-Way
• Flow Coefficient: 7.5 cv
• Connection: NPT
• Close-Off Pressure: 250 PSI
• Control Signal: Proportional (2 to 10 VDC, 4 to 20 mA)
• Loss of Power Position: Normally closed
• Protection Rating: NEMA 2
• Operating Fluid Temperature: -7 to 138 °C
