Schneider Electric VS-7223-537-4-03 SmartX Globe Valve Assembly 1/2 in 2-way

Product Description

The Schneider Electric VS-7223-537-4-03 is a SmartX globe valve assembly designed for efficiency and reliability. This 2-way valve assembly features a half-inch body size and operates with a spring return mechanism. With a flow coefficient of 2.2 cv and a close-off pressure rating of 250 PSI, it is suitable for various applications requiring precise control of fluid flow.

• Body Size: 1/2 in
• Configuration: 2-Way
• Type: Globe

Product Highlights

This valve assembly integrates seamlessly into existing systems and offers easy manual override with a standard allen wrench, ensuring functionality in case of power loss. Designed for a wide range of temperature operations, it can handle fluids between negative seven to one hundred thirty-eight degrees Celsius.

Product Information

Standard Information

• Brand: Schneider Electric
• Country of Origin: US

Technical Specifications

• MPN: VS-7223-537-4-03
• Flow Coefficient: 2.2 cv
• Close-Off Pressure: 250 PSI
• Power Input Voltage: 24 VAC/VDC, 22 to 30 VDC
• Torque: 35 in-lb
• Control Signal Range: 2 to 10 VDC, 4 to 20 mAdc
