Schneider Electric VS-7223-537-4-02 SmartX Globe Valve Assembly 1/2 in 2-Way

Product Description

The Schneider Electric VS-7223-537-4-02 is a SmartX globe valve assembly designed for efficient fluid control. This valve features a half-inch body size and operates in a two-way configuration. It is suitable for use in various systems that require reliable flow regulation.

• Body Size: 1/2 in
• Standard Configuration: 2-Way
• Power Input: 24 VAC/VDC

Product Highlights

Ideal for HVAC applications, this globe valve assembly provides precise control and high reliability.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Schneider Electric

Technical Specifications

• MPN: VS-7223-537-4-02
• Close-Off Pressure: 250 PSI
• Flow Coefficient: 1.3 cv
• Actuator Type: Electric
• Control Signal Range: 2 to 10 VDC, 4 to 20 mAdc
• Loss of Power Type: Spring Return
• Ambient Air Temperature for Operation: -30 to 60 °C
• Operating Fluid Temperature: -7 to 138 °C
• Protection Rating: NEMA 2
• Torque: 35 in-lb
