Schneider Electric VS-7223-537-4-01 SmartX Globe Valve Assembly 1/2 in 2-way VS-7223-537-4-01

Product Description

Schneider Electric VS-7223-537-4-01 is a globe valve assembly with a half-inch body size and a 2-way configuration. This assembly operates with a brass trim and is suitable for use in HVAC and plumbing systems. It has a flow coefficient of 0.4 cv and can handle a close-off pressure of 250 PSI. The actuator type is electric with a spring return, meaning it normally closes when power is lost. The product is rated for operation at 24 VAC or VDC and features a plenum-rated connection for flexibility in installation.

• Body Material: Brass
• Power Input: 24 VAC/VDC
• Torque: 35 in-lb

Product Highlights

The Schneider Electric VS-7223-537-4-01 is designed for efficient flow control in various applications. It includes a manual override and features a rotary motion actuator, making it versatile in operation.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Country of Origin: US

Technical Specifications

• Body Size: 1/2 in
• Configuration: 2-Way
• Flow Coefficient: 0.4 cv
• Close-Off Pressure: 250 PSI
• Actuator Type: Electric
• Control Signal: Proportional (2 to 10 VDC, 4 to 20 mA)
• Spring Return Position: Normally Closed
• Protection Rating: NEMA 2
