Schneider Electric VS-7223-536-4-10 SmartX Globe Valve Assembly 1-1/2 in 2-way Replacement MPN

Product Description

The Schneider Electric VS-7223-536-4-10 is a globe valve assembly designed for effective fluid control. This model features a one and a half inch body size and is configured as a two-way valve. It operates with an electric actuator and is suitable for a wide range of applications in HVAC systems.

• Body Size: 1-1/2 in
• Type: Globe
• Actuator Type: Electric

Product Highlights

This valve ensures efficient operation with a flow coefficient of twenty-eight cv. It supports a close-off pressure of fifty PSI, making it reliable for various pressure conditions. The spring return feature also guarantees normal closure when power is lost.

Product Information

Standard Information

• Brand: Schneider Electric
• MPN: VS-7223-536-4-10

Technical Specifications

• Configuration: 2-Way
• Body Pattern: Straightway
• Connection: NPT
• Flow Coefficient: 28 cv
• Power Input Voltage: 24 VAC/VDC, 22 to 30 VDC
• Torque: 35 in-lb
• Material Trim: Brass
• Mechanical Movement: Rotary
• Operating Fluid Temperature: -7 to 138 °C
• Saturated Steam Temperature: -7 to 138 °C
• Protection Rating: NEMA 2
