Schneider Electric VS-7223-536-4-08 SmartX Globe Valve Assembly 1 In 2-Way

Product Description

Schneider Electric VS-7223-536-4-08 is a globe valve assembly. This assembly features a one-inch body size and serves as a two-way valve, designed for controlling fluid flow in HVAC systems. It operates under a pressure of one hundred twenty-five PSI and supports both electric control signals and manual override.

• Body Material: Brass
• Actuator Type: Electric
• Torque: Thirty-five in-lb

Product Highlights

This valve assembly is suitable for diverse applications, including dampers and globe valve setups. Its robust construction ensures reliability in controlling fluid temperatures from negative seven to one hundred thirty-eight degrees Celsius.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Country of Origin: US

Technical Specifications

• Valve Body: VB-7223-0-4-08
• Flow Coefficient: 14 cv
• Control Signal Range: 2 to 10 VDC, 4 to 20 mAdc
• Power Input Voltage: 24 VAC/VDC
• Mechanical Movement: Rotary
• Protection Rating: NEMA 2
• Ambient Air Temperature for Operation: -30 to 60 °C
• Relative Humidity: 5-95% non-condensing
