Schneider Electric VS-7223-536-4-06 SmartX Valve Assembly 3/4 in 2-way Replacement MPN

Product Description

Schneider Electric VS-7223-536-4-06 is a SmartX Globe Valve Assembly designed for efficient temperature control in HVAC systems. This assembly features a three-quarter inch size with a two-way configuration for direct control of fluid flow.

• Efficient flow regulation with a flow coefficient of 7.5 cv
• Durable construction rated for a close-off pressure of 250 PSI
• Spring return mechanism for reliable normal closure

Product Highlights

Ideal for controlling hot or cold water, this valve assembly is suitable for various applications in commercial and residential settings.

Product Information

Standard Information

• Brand: Schneider Electric
• MPN: VS-7223-536-4-06

Technical Specifications

• Body Size: 3/4 in
• Configuration: 2-Way
• Flow Coefficient: 7.5 cv
• Close-Off Pressure: 250 PSI
• Power Input Voltage: 24 VAC/VDC
• Torque: 35 in-lb
• Operating Fluid Temperature: -7 to 138 °C
• Ambient Air Temperature For Operation: -30 to 60 °C
• Ambient Air Temperature For Storage: -40 to 71 °C
• Control Signal Range: 2 to 10 VDC
• Protection Rating: NEMA 2
