Product Description
The Schneider Electric VK-8223-602-5-13 is a globe valve assembly designed for pneumatic control applications. This valve features a flanged connection and is suitable for various operating fluids including glycol, steam, and water. With an impressive flow coefficient of eighty-five and a close-off pressure capability of up to one hundred twenty-five psi, it is ideal for controlling fluid flow effectively.
- Balanced plug technology for enhanced performance
- Excellent close-off capability up to one hundred twenty-five psi
- Self-adjusting spring-loaded packing system
Product Highlights
This globe valve is constructed with a cast iron body and brass trim for durability. Its pneumatic actuator operates within a range of five to ten psi. The diaphragm has a total effective area of fifty square inches, ensuring reliable and consistent operation.
Product Information
Standard Information
-
Brand: Schneider Electric
-
MPN: VK-8223-602-5-13
Technical Specifications
-
Size: Three inches
-
Type: Two-way globe
-
Connection: Flanged
-
Stem Flow Action: Up closed
-
Flow Characteristic: Modified equal percentage
-
Operating Conditions: Twenty degrees Fahrenheit to two hundred eighty-one degrees Fahrenheit
-
Diaphragm Area: Fifty square inches
-
Stroke Length: One inch
