Schneider Electric VK-7283-613-4-10 Valve Actuator Assembly 2-Way 1-1/2 in

Product Description

Schneider Electric VK-7283-613-4-10 is a valve actuator assembly suitable for various applications. This assembly features a globe design that provides efficient flow control. The valve is constructed with a body size of one and one half inches and is configured as a two-way valve. The actuator type is pneumatic, making it effective for controlling fluid flow.

• Body Size: 1-1/2 in
• Configuration: 2-Way
• Type: Globe

Product Highlights

This valve actuator assembly is ideal for HVAC systems and industrial applications where precise flow regulation is needed.

Product Information

Standard Information

• Brand: Schneider Electric
• MPN: VK-7283-613-4-10

Technical Specifications

• Body Pattern: Straightway
• Connection: NPT
• Flow Coefficient: 28 cv
• Close-Off Pressure: 170 PSI
• Control Signal: Proportional
• Control Spring Range: 8 to 13 PSIG
• Loss of Power Position: Normally closed
• Mechanical Movement: Linear
• Protection Rating: NEMA 1
• Operating Fluid Temperature: -7 to 204 °C
• Ambient Air Temperature for Operation: -28.8 to 104.4 °C
• Ambient Air Temperature for Storage: -40 to 104.4 °C
