Schneider Electric VK-7222-303-4-02 Valve Assembly 2-Way Globe 5/8 Inch Replacement MPN

Product Description

Schneider Electric VK-7222-303-4-02 is a valve assembly designed for efficient fluid control. This valve features a five-eighths inch body size and a two-way globe configuration suitable for various applications. The straightway body pattern allows for optimal flow performance.

• Body Size: 5/8 inch
• Configuration: 2-Way
• Actuator Type: Pneumatic

Product Highlights

This valve is built for reliability and performance in fluid control systems. The valve's construction features a brass trim and a close-off pressure rating of ten PSI. Its pneumatic actuator provides precise control, making it ideal for industrial applications.

Product Information

Standard Information

• Brand: Schneider Electric
• Country Origin: US

Technical Specifications

• Flow Coefficient: 1.3 cv
• Close-Off Pressure: 10 PSI
• Control Signal: 2-Position (On/Off), Proportional
• Control Spring Range: 10 to 13 PSIG
• Leads and Connections: 1/8 inch Air NPT
• Protection Rating: NEMA 1
• Ambient Air Temperature For Operation: -28.8 to 104.4 °C
• Ambient Air Temperature For Storage: -40 to 104.4 °C
• Mechanical Movement: Linear
