Schneider Electric VF-2253-526-9-75 Ball Valve Electric Actuator Assembly

Product Description

The Schneider Electric VF-2253-526-9-75 is a ball valve actuator assembly designed for efficient flow control in various applications. This assembly includes a two-way ball valve made from stainless steel, providing robust durability. The electric actuator operates on a power input of twenty-four volts alternating current or between twenty-two to thirty volts direct current. This actuator is suitable for systems where a loss of power may occur, utilizing a spring return mechanism to maintain the normally closed position.

• Body size: Two and a half inches
• Flow coefficient: One hundred sixty-two cv
• Protection rating: NEMA 2

Product Highlights

This assembly is ideal for HVAC systems, allowing for manual override with a five thirty-second inch allen wrench. The product is not designed for steam applications, making it suitable for a range of other fluid control tasks.

Product Information

Standard Information

• Brand: Schneider Electric
• Country of Origin: US

Technical Specifications

• Valve Type: Ball
• Actuator Type: Electric, rotary
• Close-Off Pressure: Seventy PSI
• Torque: Thirty-five in-lb
• Operating Fluid Temperature: Negative seven to one hundred twenty-one degrees Celsius
• Ambient Air Temperature for Operation: Negative thirty to sixty degrees Celsius
• Relative Humidity: Five to ninety-five percent non-condensing
• IP Degree of Protection: IP11
