Schneider Electric VB-7221-0-4-09 Series VB-7000 Two-Way Globe Valve Body, Union Straight Pipe End Connection, Stem Up Closed, Brass Plug, 1-1/4 Port Size

Product Description

The Schneider Electric VB-7221-0-4-09 Series VB-7000 is a two-way globe valve body designed for efficient control in HVAC systems. It features a union straight pipe end connection, stem up closed configuration, and a brass plug. Ideal for chilled water, hot water, and steam applications, this valve body offers precise regulation and reliable performance.

• High range ability for accurate control
• Tight sealing with low energy leakage
• High differential-pressure rating

Product Highlights

This valve body is suitable for a range of HVAC applications, ensuring energy efficiency and reliable operation even under high differential pressures. It supports Schneider Electric actuators and meets various environmental and safety standards.

Product Information

Standard Information

• Brand: Schneider Electric
• MPN: VB-7221-0-4-09
• Model: VB-7000

Technical Specifications

• Port Size: 1-1/4 inches
• Connection Type: Union Straight Pipe End
• Stem Position: Up Closed
• Plug Material: Brass
• Pressure Rating: Up to 87 psi
• Compliance: RoHS, ANSI, PED, CRN
• Application: Chilled Water, Hot Water, Steam
