Schneider Electric VA-7263-804-4-04 Valve Actuator Assembly 2-Way Globe Valve

Product Description

Schneider Electric VA-7263-804-4-04 is a valve actuator assembly designed for efficient control in various applications. This device features a 2-way globe valve configuration with a stainless steel trim, ensuring durability and reliability. The actuator operates on 24 VAC/VDC and supports a control signal capability of 2-position (On/Off).

• Body Size: 1/2 in
• Control Signal: 2-Position
• Flow Coefficient: 4.4 cv

Product Highlights

This valve actuator is suitable for HVAC systems and other fluid control applications. It offers a powerful electric actuator with a spring return feature, making it effective in various environmental conditions.

Product Information

Standard Information

• Brand: Schneider Electric
• Country of Origin: US

Technical Specifications

• MPN: VA-7263-804-4-04
• Actuator Type: Electric
• Close-Off Pressure: 250 PSI
• Flow Coefficient: 4.4 cv
• Operating Fluid Temperature: -7-171 °C
• Protection Rating: NEMA 2
• Power Input Voltage: 24 VAC/VDC
• Force: 105 lbf
