Schneider Electric V6 30 x 100 mm 600 Volt 115 Amp 3-Pole Manual Motor Control Switch Body

Product Description

The Schneider Electric V6 is a three-pole switch body used with the TeSys Vario switch-disconnector. It is rated for one hundred seventy-five amps and six hundred ninety volts. This switch body is suitable for motor applications up to forty-five kilowatts at four hundred volts AC-23. It can be fitted with a handle and extension shaft to serve as a main or emergency stop switch-disconnector. Add-on modules such as the main pole, neutral pole, earthing module, and auxiliary contacts can be added to complete the assembly.

• Three-pole design for versatility in applications.
• Supports motor loads up to forty-five kilowatts.
• Globally certified and compliant with multiple standards.

Product Highlights

This switch body is certified by IEC, UL, CSA, CCC, EAC, and Marine standards. It also meets Green Premium compliance for RoHS and REACH.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Square-D / Schneider

Technical Specifications

• Catalog Number: V6
• Weight: 1.98 lb
• Dimensions: 3.54 in x 3.54 in x 4.92 in (width x depth x height)
• Voltage Rating: 690 Volt
• Amperage Rating: 175 Amp
• Operating Temperature: -41 to 122 degrees F
• Country of Origin: Czech Republic
• Warranty Length: 18 months
