Schneider Electric TM241CE24R Square D 24 I/O Relay Ethernet M241 Controller

Product Description

The Schneider Electric TM241CE24R is a logic controller within the Modicon M241 range. It is suitable for demanding applications and offers 14 discrete inputs, 8 fast inputs, 6 relay outputs, 4 transistor outputs, and 4 fast outputs featuring Ethernet relay output. This unit has a supply voltage range from one hundred volts to two hundred forty volts AC. Additionally, it supports output voltages from five volts to one hundred twenty-five volts DC or five volts to two hundred fifty volts AC for relay outputs, and twenty-four volts DC for transistor outputs. The output current capacity includes two amps for relay outputs, one hundred milliamps for fast outputs, and five hundred milliamps for transistor outputs. Its intuitive design enhances application development.

• Integrated connections include a USB port with a mini B connector, a non-isolated serial link with RJ45, and RS232/RS485 interfaces.
• This controller features eight megabytes for program memory, sixty-four megabytes for system memory, and a built-in flash memory capacity of one hundred twenty-eight megabytes. It can also accommodate an optional sixteen gigabyte SD card.
• IP20 rated with dimensions of one hundred fifty millimeters in width, ninety-five millimeters in depth, and ninety millimeters in height, weighing zero point five three kilograms.

Product Highlights

The Modicon M241 is engineered for compact, high-performance machines, offering speed and position control functions. Integrated with EcoStruxure Machine Expert, it allows easy machine programming and access to ready-to-use applications and function blocks.

Product Information

Standard Information

• Catalog Number: TM241CE24R
• Manufacturer: Schneider Electric

Technical Specifications

• Type: Logic controller
• Memory: 8 MB PROGRAM, 64 MB SYSTEM MEMORY RAM, up to 16 GB SD CARD OPTIONAL
• Operating Temperature: -10 to 55 degrees C for horizontal installation; -10 to 50 degrees C for vertical installation
• Response Time: 50 ms turn-on, I0...I13 input
• Certifications: ABS, CE, CULus, DNV-GL, LR, RCM, UKCA
• Power Supply: 100V - 240V AC
• Dimensions: 150 mm width x 95 mm depth x 90 mm height
• Net Weight: 0.53 kg
