Schneider Electric STBNIC2212 SQD STBNIC2212 standard Network Int 24V DC

Product Description

Schneider Electric STBNIC2212 is a standard network interface module from the Modicon STB range. This product supports one primary segment and a maximum of six extension segments. It operates with a rated supply voltage of twenty-four volts direct current and provides a maximum supply current of seven hundred amperes. The output voltage is five point twenty-five volts direct current with an output current of one point two amperes. This module offers embedded web communication, BootP/DHCP protocol, and SNMP agent services. It can integrate with major fieldbus networks and requires SELV power supply. It is designed with an IP20 rating and its dimensions are one hundred twenty-eight point three millimeters in width, seventy millimeters in depth, and forty millimeters in height, weighing zero point one four five kilograms. This module is suitable for various applications including packaging, bottling, textile production, printing, and semiconductor machinery.

• Supports one primary and up to six extension segments
• Rated for use with 24V DC power
• IP20 rated for environmental protection

Product Highlights

Offers flexible integration for automation systems and machine control applications.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Catalog Number: STBNIC2212

Technical Specifications

• Supply Voltage: 24 V DC
• Output Voltage: 5.25 V DC
• Output Current: 1.2 A
• Width: 128.3 mm
• Depth: 70 mm
• Height: 40 mm
• Weight: 0.145 kg
• Certifications: CE, CSA, UL
