Schneider Electric SSP3A250B7 Solid State Relay 3 Phase 50A at 48-530VAC 18-36VAC

Product Description

The Schneider Electric SSP3A250B7 Solid State Relay brings streamlined efficiency and reliability to industrial settings. Specifically designed for three-phase application, this solid state relay offers robust performance at a rated amperage of 50 Amps, capable of handling output voltages from 48 to 530 volts AC. Engineered for long-term dependability, the SSP3A250B7 comes in a compact structure which simplifies installation processes and optimizes space utilization.

• Maintains steady operation at a control circuit voltage between 18 and 36 volts AC.
• Includes a maintenance-free, unlimited lifespan, fully electronic composition.
• Features a convenient LED indicator for monitoring control input voltage.

Product Highlights

Beneficial for diverse industrial uses such as packaging, plastic molding, and textile operations. Its robust design ensures consistent performance even in demanding environments. Equipped with IP20 protection, it secures against touch and foreign object damage. The relay's solid-state technology ensures fast response and high efficiency during operations.

Product Information

Standard Information

• Brand: Schneider Electric
• MPN: SSP3A250B7

Technical Specifications

• Type: Solid state relay
• Phase: 3 Phase
• Contact Configuration: 3NO
• Control Voltage: 18-36V AC
• Output Voltage: 48-530V AC
• Weight: 0.53 lb (240 g)
• Dimensions: Width 101.3 mm, Height 79.7 mm, Depth 35.4 mm
• Certifications: CSA, UL
• Operating Temperature: -40 to 80 degrees Celsius
