Square D 8911DPSO23V02 Definite Purpose Starter 110/120 VAC 25 Amp 20 Hp

Product Description

The Square D 8911DPSO23V02 magnetic motor starter is engineered for high performance and durability in various industrial applications including air compressors, agricultural machinery, pumps, and HVAC systems. It simplifies powering devices with a 110/120 VAC coil, supporting up to 20 horsepower three-phase motors.

• Three-pole, 25 amp configuration ensures optimal conductivity.
• Designed for low-duty cycle operations to reduce wear and extend service life.
• Open device without an enclosure for easy integration and maintenance.

Product Highlights

This starter features straight-through wiring and a melting alloy overload relay, utilizing Type B thermal units to effectively manage overcurrent situations. UL component recognition underscores compliance with rigorous safety standards.

Product Information

Standard Information

• Brand: Square D
• MPN

Technical Specifications

• Voltage: 110/120 VAC
• Amperage: 25A
• Phase: 3 Phase
• Coil Voltage: 110/120 VAC 50/60 Hz
• Number of Poles: 3 Pole
• Enclosure: Not Rated
• Height: 6.73 inches
• Width: 3.50 inches
• Depth: 4.09 inches
