Schneider Electric SER8350A5B11 SE8000 Series Power Room Controller

Product Description

The Schneider Electric SER8350A5B11 is a line-voltage fan coil room controller designed to manage comfort and efficiency in HVAC systems. This controller uses BACnet MS/TP for communication, and it features an integrated relative humidity sensor, a temperature sensor, and a PIR motion sensor for energy savings. This product requires an SC3000 relay pack to control the fan coil unit and a communication module (VCM8000V5045P) for Zigbee Pro, sold separately.

• Supports BACnet MS/TP communication
• Includes RH and temperature sensors
• PIR motion sensor for enhanced energy efficiency

Product Highlights

Ideal for use in various applications including residential, hotels, and commercial buildings, this room controller allows for precise control of comfort conditions while optimizing energy use.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Schneider Electric

Technical Specifications

• MPN: SER8350A5B11
• Product Type: Room Controller
• Height: 4.7 cm
• Width: 10.6 cm
• Length: 15.2 cm
• Weight: 220 g
• Operating Temperature: 0-50 °C
• Storage Temperature: -30-50 °C
• Relative Humidity: 0-95 %
• Connection Type: 2 x dry contact, 5 x analog
• Power Supply: 0.166666667 A
