Schneider Electric REXL4TMF7 Square D 120 VAC 5 Amp Timer Relay

Product Description

This Schneider Electric REXL4TMF7 is a multi-function timing relay designed to operate between 0.1 seconds and 100 hours. It features a robust output rating of 5A and is compatible with a 120V AC power supply. The relay has a compact design, with a width of twenty-one millimeters, allowing for easy integration into various control and automation systems. It is a plug-in unit that simplifies installation; no tools are required.

• Easy to install with plug-in design
• Adjustable settings using rotary trimmers
• Visual status monitoring with dual LEDs

Product Highlights

Ideal for applications needing precise timing control, the REXL4TMF7 supports fast installation and operation feedback through visual indicators.

Product Information

Standard Information

• Catalog Number: REXL4TMF7
• Manufacturer: Schneider Electric

Technical Specifications

• Amperage: 5 Amp
• Weight: 0.11 lb
• Country of Origin: Indonesia
• Timing Range: 0.1 seconds to 100 hours
• Operating Temperature: -20 to 60 degrees Celsius
• Contact Configuration: 4 C/O
• Warranty Length: 18 months
• Certifications: CUL, UL
