Schneider Electric NSYTRR42PE Terminal Block, Line

Product Description

The Schneider Electric NSYTRR42PE is a terminal block designed for Linergy applications. It features a four millimeter nominal cross-section and a grey surface treatment. The mounting process is simple with clip-on installation, and it connects through single-level screw terminals. A flat screwdriver facilitates easy connection and disconnection. This terminal block is compatible with various enclosures like Prisma G, Prisma P, Pragma, Prisma PH, Prisma Pack, Spacial, Kaedra, and TeSys. Each package contains fifty units. Operating temperature ranges from minus forty degrees Celsius to one hundred thirty degrees Celsius, in compliance with IEC 60216-1 and VDE 0304-T21 standards. This product is certified under multiple standards including ATEX, CSA, cURus, DNV, GL, LR, VDE, IEC-Ex, and EAC. Additionally, it meets Green Premium requirements (RoHS/REACH).

• Compatible with various spacial enclosures.
• Simple clip-on installation.
• Wide operating temperature range.

Product Highlights

This terminal block supports robust performance across diverse applications, making it suitable for different electrical connections.

Product Information

Standard Information

• Catalog Number: NSYTRR42PE
• Manufacturer: Schneider Electric

Technical Specifications

• Type: Protective earth; Terminal block; Spacial enclosures
• Material: Polyamide
• Width: 6.2 mm
• Height: 36.5 mm
• Length: 56 mm
• Weight: 0.45 oz
• Wire Size: 4 mm
• Number of Terminations: 2
