Schneider Electric NSYTRR22PE SQD Terminal Block, Line

Product Description

The Schneider Electric NSYTRR22PE is a terminal block for Linergy applications. This product features a nominal cross section of 2.5 millimeters and is designed for protective earth connectivity. The grey surface is treated for durability.

• Mounting by clip-on for easy installation.
• Compatible with various Prisma enclosures like G, P, and PH.
• Temperature range from -40 to 130 degrees Celsius.

Product Highlights

This product is certified to multiple standards including ATEX, CSA, cURus, DNV, GL, LR, VDE, IEC-Ex, and EAC.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Brand: Square-D / Schneider

Technical Specifications

• Catalog Number: NSYTRR22PE
• Connection Type: 1 x spring terminal upstream; 1 x spring terminal downstream
• Material: Polyamide 6/6
• Dimensions: Length 48.5 mm x Width 5.2 mm x Height 36.5 mm
• Weight: 0.35 oz (10 g)
• Mounting Type: Clip-On
• Warranty: 18 months
• Country of Origin: United States
